SV-DA200 series AC servo drive Function codes
-105-
Note:
1. This parameter is valid when P0.40 is set to “1”.
2. Set the parameter correctly after confirming the motor operation condition, if this parameter is
set to a large value, the motor speed will fluctuate violently.
P0.42
Data size
32bit
Data format
DEC
Modbus address
1084, 1085
CANopen address
0x202A, 0x00
P0.43
Analog input 1 reverse
Setting range
Default
Unit
Available mode
0–1
0
-
P
S
T
Set the voltage polarity of analog input 1.
Setting value
Actual detection result
[0]
Positive polarity
[+voltage]→[positive value],[- voltage]→[negative value]
1
Negative polarity
[+voltage]→[negative value],[- voltage]→[positive value]
P0.43
Data size
16bit
Data format
DEC
Modbus address
1086, 1087
CANopen address
0x202B, 0x00
P0.45
Dead zone of analog
input 1
Setting range
Default
Unit
Available mode
0.000–3.000
0.000
V
P
S
T
If the absolute value of analog input 1 voltage is within this range, the corresponding command
value is 0.
P0.45
Data
16bit
Data format
DEC
Modbus address
1090, 1091
CANopen address
0x202D, 0x00
P0.46
Internal speed 1/Speed limit 1
Setting range
Default
Unit
Available mode
-20000–20000
100
r/min
S
T
P0.47
Internal speed 2/Speed limit 2
Setting range
Default
Unit
Available mode
-20000–20000
0
r/min
S
T
P0.48
Internal speed 3/Speed limit 3
Setting range
Default
Unit
Available mode
-20000–20000
0
r/min
S
T
P0.49
Internal speed 4/Speed limit 4
Setting range
Default
Unit
Available mode
-20000–20000
0
r/min
S
T
P0.50
Internal speed 5
Setting range
Default
Unit
Available mode
-20000–20000
0
r/min
S
P0.51
Internal speed 6
Setting range
Default
Unit
Available mode
-20000–20000
0
r/min
S
P0.52
Internal speed 7
Setting range
Default
Unit
Available mode
-20000–20000
0
r/min
S
P0.53
Internal speed 8
Setting range
Default
Unit
Available mode
-20000–20000
0
r/min
S
There are 8 internal speed commands and 4 internal speed limits.
