INVT SV-DA200-7R5-4 User Manual

SV-DA200 series AC servo drive Function codes
-174-
P5.61
08 delay time
Setting range
Default
Unit
Available mode
0–32767
2000
ms
P
P5.62
09 delay time
Setting range
Default
Unit
Available mode
0–32767
2500
ms
P
P5.63
10 delay time
Setting range
Default
Unit
Available mode
0–32767
3000
ms
P
P5.64
11 delay time
Setting range
Default
Unit
Available mode
0–32767
3500
ms
P
P5.65
12 delay time
Setting range
Default
Unit
Available mode
0–32767
4000
ms
P
P5.66
13 delay time
Setting range
Default
Unit
Available mode
0–32767
4500
ms
P
P5.67
14 delay time
Setting range
Default
Unit
Available mode
0–32767
5000
ms
P
P5.68
15 delay time
Setting range
Default
Unit
Available mode
0–32767
5500
ms
P
These parameters are used to set the delay time of each step bit.
P5.53
Data size
16bit
Data format
DEC
Modbus address
2106, 2107
CANopen address
0x2535, 0x00
P5.54
Data size
16bit
Data format
DEC
Modbus address
2108, 2109
CANopen address
0x2536, 0x00
P5.55
Data size
16bit
Data format
DEC
Modbus address
2110, 2111
CANopen address
0x2537, 0x00
P5.56
Data size
16bit
Data format
DEC
Modbus address
2112, 2113
CANopen address
0x2538, 0x00
P5.57
Data size
16bit
Data format
DEC
Modbus address
2114, 2115
CANopen address
0x2539, 0x00
P5.58
Data size
16bit
Data format
DEC
Modbus address
2116, 2117
CANopen address
0x253A, 0x00
P5.59
Data size
16bit
Data format
DEC
Modbus address
2118, 2119
CANopen address
0x253B, 0x00
P5.60
Data size
16bit
Data format
DEC
Modbus address
2120, 2121
CANopen address
0x253C, 0x00
P5.61
Data size
16bit
Data format
DEC
Modbus address
2122, 2123
CANopen address
0x253D, 0x00
P5.62
Data size
16bit
Data format
DEC
Modbus address
2124, 2125
CANopen address
0x253E, 0x00
P5.63
Data size
16bit
Data format
DEC
Modbus address
2126, 2127
CANopen address
0x253F, 0x00

INVT SV-DA200-7R5-4 Specifications

General

Power	7.5 kW
Output Current	17 A
Frequency Range	0-400Hz
Cooling Method	Forced air cooling
Storage Temperature	-20°C to +60°C
Input Voltage	Three-phase 380V to 440V
Output Voltage	0 to Input Voltage
Control Mode	V/F control
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short circuit
Communication Interface	RS485
Operating Temperature	-10°C to 50°C
Humidity	5% to 95% non-condensing
Altitude	≤1000 m
