SV-DA200 series AC servo drive Appendix
-273-
Function
code
Name
Unit
Range
Default
Available
Mode
P3.28
Analog speed compensation gain
%
0.0–100.0
0.0
P
P3.29
Analog torque compensation gain
%
0.0–100.0
0.0
PST
P3.30
1
Analog output 1 function selection
-
0–19
0
PST
P3.31
Voltage gain of analog output 1
[P3.30 unit]/V
1–214748364
1
PST
P3.32
1
Analog output 2 function selection
-
0–19
0
PST
P3.33
Voltage gain of analog output 2
[P3.30 unit]/V
1–214748364
1
PST
P3.34
Offset voltage of analog output 1
V
-10.000–10.000
0.000
PST
P3.35
Offset voltage of analog output 2
V
-10.000–10.000
0.000
PST
P3.36
1
Analog output monitor setting
-
0–2
0
PST
P3.40
1
Travel limit switch shield
-
0–2
1
PST
P3.41
1
Emergency stop switch shield
-
0–1
1
PST
P3.43
1
Digital input filter
0.125ms
1–800
1
PST
P3.44
Command pulse input invalid
setting disabled
-
0–1
0
P
P3.45
1
Clearing mode of retention pulse
-
0–1
1
P
P3.50
Range of position arrival
reference unit
0–2
18
100
P
P3.51
Output mode of position arrival
-
0–4
0
P
P3.52
Hold time of position arrival output
terminal
ms
0–30000
0
P
P3.53
Speed matching range
r/min
10–20000
50
PST
P3.54
Speed reaching range
r/min
10–20000
1000
PST
P3.55
Zero speed range
r/min
10–20000
50
PST
P3.56
Locked time of servo after braking
ms
0–1000
50
PST
P3.57
Braking delay of electromagnetic
brake
ms
0–30000
500
PST
P3.58
1
Motor speed of brake release
r/min
0–1000
30
PST
P3.59
Torque reaching range
%
5.0–300.0
50.0
T
P3.70
1
Analog input 3 function selection
-
0–7
4
PST
P3.71
Zero offset of analog input 3
V
-10.000–10.000
0.000
PST
P3.72
Dead zone of analog input 3
V
0.000–3.000
0.000
PST
P3.73
Gain of analog input 3
[P3.70 unit]/V
0–2000
300
PST
P3.74
Analog input 3 reverse
-
0–1
0
PST
P3.75
Voltage protection of analog input 3
V
0.000–10.000
0.000
PST
P3.76
Analog input 3 filter
ms
0.0–1000.0
0.0
PST
P3.77
Deadzone mode of analog input
-
0–1
0
PST
P3.90
Pulse input filter
-
0–7
2
PST
P3.91
Reserved
-
-
-
PST
