LBK System| Instruction manual v1.3 SEP 2019 |LBK-System_instructions_en v1.3|© 2018-2019 Inxpect SpA
Parameter Min Max Default value
Setting Digital Input/Output
Digital input (for each input) Not configured, Stop signal, Restart signal, Muting group 1,
Muting group 2, Muting group 3
Not
configured
Digital output (for each
output)
Not configured, Pre-alarm signal, Muting enable feedback
signal, System diagnostic signal
Not
configured
Settings Muting
Group for muting (for each
sensor)
Group 1, Group 2, Group 3 Group 1
Pulse width (for each Input
TYPE)
0 us (= Period and Phase shift
disabled)
200 us
2000 us 0 us
Period (for each Input TYPE) 200 ms 2000 ms 200 ms
Phase shift (for each Input
TYPE)
400 us 1000 ms 400 us
Configuration
Number of installed sensors 1 6 1
Distance between sensors 0 mm 10000 mm 0mm
BARRIER LENGTH 0 mm 15000 mm 0mm
Actual length 0 mm 10000 mm 1581 mm
Plane Dim. X: 2000 mm
Dim. Y: 1000 mm
Dim. X: 20000 mm
Dim. Y: 20000 mm
Dim. X: 8000
mm
Dim. Y: 4000
mm
Position (for each sensor) X: 0 mm
Y: 0 mm
X: 20000 mm
Y: 20000mm
X: 2000 mm
Y: 1000 mm
Alarm distance (for each
sensor)
1000 mm 4000 mm 1500 mm
Pre-alarm distance (for each
sensor)
0 mm 3000 mm 500 mm
Rotation (for each sensor) 0° 360° 0°
Inclination (for each sensor) 0° 360° 0°
Sensor installation height
(for each sensor)
0 mm 3000 mm 0 mm
Field of vision (for each
sensor)
110°, 50° 110°
Safety functions (for each
sensor)
Both (default), Always access detection, Always restart
prevention
Both (default)
