11.b-2 Specifications, Plotted Data
967692 IOtech 640 and 650 Series
Figure I.
Not applicable. Figure 1has been removed.
Figure II. Measurement High Pass Filter Response
Measurement High Pass Filter Response
-35
-30
-25
-20
-15
-10
-5
0
5
0.01 0.10 1.00 10.00 100.00
Frequency
Amplitude (dB)
650
640
