IOtech 640 and 650 Series
967692 Specifications, Plotted Data 11.b-3
Figure III. 640 Measurement Delay vs. Frequency, DC-Coupled
640 Measurement Delay vs Frequency DC Coupled
-1E-6
-800E-9
-600E-9
-400E-9
-200E-9
000E+0
200E-9
400E-9
600E-9
800E-9
1E-6
0 5000 10000 15000 20000 25000 30000 35000 40000 45000 50000
Frequency (Hz)
Delay (sec)
Figure IV. 640 Measurement Delay vs. Frequency, AC-Coupled
640 Measurement Delay vs Frequency AC coupled
-200E-6
-150E-6
-100E-6
-50E-6
000E+0
50E-6
0 200 400 600 800 1000 1200 1400 1600 1800 2000
Frequency (Hz)
Delay (sec)
