IOtech 640 - Page 78

Specifications are subject to change without notice.
11.b-4 Specifications, Plotted Data
967692 IOtech 640 and 650 Series
Figure V. 650 Measurement Delay vs. Frequency, DC-Coupled
640 Measurement Delay vs Frequency DC Coupled
-2.0E-6
-1.5E-6
-1.0E-6
-500.0E-
9
000.0E+
0
500.0E-
9
1.0E-6
1.5E-6
2.0E-6
0 5000 10000 15000 20000 25000 30000 35000 40000 45000 50000
Frequency (Hz)
Delay (sec)
Figure VI. 650 Measurement Delay vs. Frequency, AC-Coupled
650 Measurement Delay vs Frequency AC Coupled
000.0E+0
1.0E-6
2.0E-6
3.0E-6
4.0E-6
5.0E-6
0 5000 10000 15000 20000 25000 30000 35000 40000 45000 50000
Frequency (Hz)
Delay (sec)
