iPECS eMG800 - Function Boards; VMIB (Voice Mail Interface Board) and AAIB (Auto-Attendant Interface Board)

iPECS eMG800
Hardware Description and Installation Manual Issue 1.8
63
4.5 Function Boards
4.5.1 VMIB (Voice Mail Interface Board) and AAIB (Auto-Attendant Interface Board)
VMIB and AAIB provide memory for System Greetings including CCR and ACD/UCD announcements.
In addition, VMIB provides memory for User Greetings and Voice Message storage, 100 hours.
VMIB and AAIB include a processor and DSP circuitry to support eight (8) simultaneous channels.
BOARD
CHANNEL
SYSTEM GREETING/USER GREETING
VMIB
8
System Greeting (0.5hrs.), User Message (100 Hours)
AAIB
8
System Greeting (0.5hrs.), User Message (None)
VMIB and AAIB have a standard USB connector that is used to back-up System and User greetings, and
Voice Messages (VMIB only).
In addition, the VMIB and AAIB have a LAN and Audio Serial port jack used for advanced diagnostic purposes
and board upgrades only.
Figure 4.5.1-1 AAIB and VMIB
NOTE
- If VMIB or AAIB is installed in System, VMIB/AAIB prompts (Default=1-English, 2-3-Blank) should be
uploaded for each country.
- System Voice prompts are stored on MPB and not on VMIB or AAIB.
- Voice prompt Language can be changed using Web Admin, VMIB upgrade function.
