iPECS ES-3052GP - Page 147

C HAPTER 5 | Interface Configuration
Trunk Configuration
– 147 –
ES-3052 Series
To configure connection parameters for a static trunk:
1. Click Interface, Trunk, Static.
2. Select Configure General from the Step list.
3. Select Configure from the Action list.
4. Modify the required interface settings. (Refer to "Configuring by Port
List" on page 127 for a description of the parameters.)
5. Click Apply.
Figure 41: Configuring Connection Parameters for a Static Trunk
To show the static trunks configured on the switch:
1. Click Interface, Trunk, Static.
2. Select Configure General from the Step list.
3. Select Show Information from the Action list.
Figure 42: Showing Information for Static Trunks
