C
HAPTER
6
| VLAN Configuration
IEEE 802.1Q VLANs
– 177 –
Configure Interface
◆ Interface – Displays a list of ports or trunks.
◆ Port – Port Identifier. (Range: 1-52)
◆ Trunk – Trunk Identifier. (Range: 1-12)
◆ GVRP Status – Enables/disables GVRP for the interface. GVRP must be
globally enabled for the switch before this setting can take effect (using
the Configure General page). When disabled, any GVRP packets
received on this port will be discarded and no GVRP registrations will be
propagated from other ports. (Default: Disabled)
GVRP cannot be enabled for ports set to Access mode (see "Adding
Static Members to VLANs" on page 171).
◆ GVRP Timers – Timer settings must follow this rule:
2 x (join timer) < leave timer < leaveAll timer
■
Join – The interval between transmitting requests/queries to
participate in a VLAN group. (Range: 20-1000 centiseconds;
Default: 20)
■
Leave – The interval a port waits before leaving a VLAN group. This
time should be set to more than twice the join time. This ensures
that after a Leave or LeaveAll message has been issued, the
applicants can rejoin before the port actually leaves the group.
(Range: 60-3000 centiseconds; Default: 60)
■
LeaveAll – The interval between sending out a LeaveAll query
message for VLAN group participants and the port leaving the
group. This interval should be considerably larger than the Leave
Time to minimize the amount of traffic generated by nodes rejoining
the group. (Range: 500-18000 centiseconds; Default: 1000)
Show Dynamic VLAN – Show VLAN
VLAN ID – Identifier of a VLAN this switch has joined through GVRP.
VLAN Name – Name of a VLAN this switch has joined through GVRP.
Status – Indicates if this VLAN is currently operational.
(Display Values: Enabled, Disabled)
Show Dynamic VLAN – Show VLAN Member
◆ VLAN – Identifier of a VLAN this switch has joined through GVRP.
◆ Interface – Displays a list of ports or trunks which have joined the
selected VLAN through GVRP.
