12 LIP-9000 Series User Guide - ST
2. LCD, Speakerphone & Related
Features
2.1 Using the LCD
The LIP-9030 and LIP-9040 each has 6-line and 8-line Liquid Crystal
Display (LCD) which is divided into 3 sections. The upper section, which
consists of a single line, displays station number, various icons, time and
flexible button page number. The middle section displays the string of flex
button or a monthly calendar (LIP-9040 Only). The user can select by
pressing CALENDR
Soft button of next page in idle state. It will also provide
called/calling name/number display, feature status and etc.
The lower section, which consists of a single line, is an interactive menu to
guide you through feature access and User Program selections. The
Navigation button is used to move through Display Menu items.
