IPS Controllers M720 - Controller Panel Descripti Ons

E. Controller Panel Descrip ons
1. Digital Displays and Func on LEDs
a. pH
1. Alert - red LED
2. Dose - green LED
b. ORP
1. Alert - red LED
2. Dose - yellow LED
Figure 2: M720 Controller Components Connec ons
8
M720 pH/ORP Controller Owner’s Manual
Electrical
Flow Cell
digital display
pushbutton
LEDs
Controller Communication
ipscontrollers.com
pH
Dose
Alert
Dose
Alert
ORP
mV
FlowAuto pH ORP
IPS-M720
AC PowerpH ORP Flow
pH
ORP
Up
MODE
Down
Set
Level
Dose
Time
Delay
Time
pH
Cal
