The starter jams during
compression of the spring
pack or fails to discharge on
tripping
The drive shaft or drive nut
threads are worn causing the
ball bearings to jam
between the nut and the
shaft.
Set trip lever to vertical
position. Turn the Winding
Adaptor anti-clockwise, until
the white springs are visible
through the window.
If the starter still cannot be
discharged
Place the starter in a strong wooden box and contact IPU for
further instructions.
WARNING Do NOT attempt to dismantle a jammed starter as this is extremely dangerous and
requires expert attention. Please contact your local IPU agent. Also keep your fingers away from
the pinion.
