Appendix 5: Anti-clockwise Starters
Pull hub out, move to full RPM.
(forward or reverse)
Switch main switch to ‘run’
Pull the reset button. Trip lever
will spring into reset position
Wind hand crank clockwise until
red springs show in sight glass.
Remove hand crank
Push trip lever to start engine
Turn hand crank
counterclockwise until white
springs show in sight glass.
Caution: - Do not dismantle or remove starter from engine unless fully unwound.
- Once the spring starter is energised it must be released or unwound.
- Do not attempt to use electric start with spring starter energised.
