IPU Spring Starter User Manual

P a g e | 5
Basic steps
After you have completed the preparation steps on page 4 below are the basic operating
procedures:
TO START
1. Gearbox must be in neutral
2. Fuel on
3. Set excess fuel
4. Open throttle
5. Pull reset button
6. Wind clockwise until RED springs are showing:
• WHITE springs visible = unwound
• RED springs visible = wound for starting
7. Operate the trip lever
TO UNWIND STARTER
Crank the handle in an anti-clockwise direction until the WHITE springs appear in the inspection
window.
CAUTION: Do not dismantle or remove starter from engine unless WHITE springs are visible.
