Quick Start Connection Guide
There are two connectors on the rear of the laser available for operation of the laser. The 15
pin “D” connector contains all the available connections for operation. The RJ-45 connector
contains a basic set of connections.
Power Cable, All Lasers
Designation
Pin
Description
Comment
Black
-
Power Ground
10 gauge wire to power supply Ground
Red
-
Power VDC positive
connection
10 gauge wire to power supply
Connector (RJ-45), All Lasers
Designation
Pin
Description
Comment
RJ-45
1
Modulation High in
TTL relative to GND or Pin 6. (Page 9)
RJ-45
2
Fault LED drive pin
Grounded Cathode.
RJ-45
3
Interlock
Grounded Interlock will enable laser.
RJ-45
4
CTL TXD
RS232 Comm line.
RJ-45
5
CTL RXD
RS232 Comm line.
RJ-45
6
Modulation low in
This line grounded or driven
independently for command line
isolation. (Page 9)
RJ-45
7
Ground
System GND.
RJ-45
8
Ground
System GND.
