Iradion Infinity 156 - Specifications (9.3µm)

26
Specifications, 9.3µm
Infinity Model
155 9.3µm
156-9.3µm
Rated Optical Power
50
60
Mode Quality (M2)
≤1.2
≤1.2
Beam Ellipticity
<1.2:1
<1.2:1
Beam Diameter (mm)1/e2
2.5
2.5
Beam Divergence (mR,
full angle)
5.2
5.2
Wavelength (μm)
9.3µm
9.3µm
Rise Time (μS)
<75
<75
Pulse Duration (μS)
10 - 200
10 - 200
Duty Cycle
0 - 100%
0 - 100%
Power Stability, Fan
Cooled, from cold start
<±7%
<±7%
Power Stability, Water
Cooled, from cold start
<±5%
<±5%
Polarization
Random
Random
Cooling
Air, fan, water
Air, fan, water
Input power (Watts)
960
1400
Input Voltage/Current
45V/25A
50V/30A
Weight (Kg/lbs)
14.7/32.4
14.7/32.4
