Table 6: Environmental Tests
Test Name Test Reference Test Description
Thermal Shock
EN60068-2-14:2000
Change of Temperature,
-25C to +70C,
5 cycles of 1 hour each
Humidity IEC60068-2-3:1969
Damp heat steady state
40C 93% RH for 4 days
Shock
EN60068-2-27:1993
(NF c20-727)
Shock J1455 Society of Automotive Engineers
Vibration EN 60068-2-36:1996
Sinusoidal Vibration
0.96 m2/s3 from 5Hz to 20Hz
Vibration IEC 60068-2-36:1996
Sinusoidal Vibration
21Hz to 500Hz
-3dB per octave
Vibration J1455 Society of Automotive Engineers
4.1 Interface Connectors
The 9601 SBD Transceiver incorporates two connectors:
• A multi-interface connector
• An antenna connector
These interfaces are described in more detail in Sections 5 and 6 respectively.
5.0 Electrical Interfaces
The subsections to follow contain information for the electrical interfaces of the 9601 SBD Transceiver.
5.1 Multi-Interface Connector
The multi-interface connector includes six interfaces:
• DC power supply input
• Power on/off control
• RS-232 Serial data
• Network available output
5.1.1 Connector Type
The connector on the 9601 is a Samtec EHT series. This connector provides the ability for both a cable
connector as well as a stackable board to board connection. For cable connected applications use the
Samtec TCSD series. For PCB stacking use the Samtec ESQT series.
Data sheets on these connectors can be found at:
EHT Series: http://www.samtec.com/technical_specifications/overview.asp?series=EHT
TCSD Series: http://www.samtec.com/technical_specifications/overview.asp?series=tcsd
ESQT Series: http://www.samtec.com/technical_specifications/overview.asp?series=esqt
