irinox ICY M - Dimensional Data

8
2.3. DIMENSIONAL DATA
FRONT VIEW SIDE VIEW TOP VIEW
765mm
Min 70 mm
Min 30 mm
815mm
63mm
63mm
80 mm ÷ 115 mm
AIR FLOW
AIR FLOW
153mm56mm
Min 75 mm
804mm
694mm
474mm
DRAIN PIPE Ø20mmDRAIN PIPE Ø20mm
400mm
383 mm
1475mm
ICY S
ICY M
ICY L
383 mm
474mm
AIR FLOW
AIR FLOW
Min 75 mm
774mm
884mm
89mm
187mm
68mm
68mm
1453mm
min 70 mm
min 30 mm
115mm ÷ 165mm
765mm
400mm
1556mm
min 70 mm
min 30 mm765mm
1829mm
68mm
68mm
115 mm ÷ 165 mm
AIR FLOW
AIR FLOW
187 mm
89 mm
min 75 mm
774mm
884mm
474mm
400mm
383mm
1556mm
DRAIN PIPE Ø20mm
