Doc. SIE10169 Rev. 13 Page 25 of 32
3.13.2 Digital transducers
The digital transducer option has the following characteristics.
. Transducer name: HENGSTLER RS0-550-170;
. Transducer type: RS422 interface; 5000 impulses per turn;
. Connection: the transducer is connected to the test set via a shielded cable, 10 m long, terminated
with a connector.
Transducer code: PII11169.
Transducer kit code: PII17169.
The mounting kit is the same as above.
3.14 HALL EFFECT CLIP-ON TRANSFORMER FOR I MEASUREMENTS, CODE PII29166.
The Hall effect clip-on transformer allows measuring the DC current of motors and of the auxiliary
supply. Main characteristics:
. Metering: AC and DC currents.
