ISA CBA2000 - 3.13 POSITION TRANSDUCERS

Doc. SIE10169 Rev. 13 Page 24 of 32
3.13 POSITION TRANSDUCERS.
3.13.1 Analog transducers
We have a set of analog transducers, linear and rotating. Linear transducers have different strokes,
and also different IP protections: low for the TLH series, high for the LWG series. A mounting kit
is also available. The table summarizes characteristics and codes.
TYPE
DESCRIPTION
STROKE (mm)
CODE
LINEAR
TLH150
150
PII11166
LINEAR
TLH225
225
PII12166
LINEAR
TLH300
300
PII13666
LINEAR
TLH500
500
PII13166
LINEAR
LWG150
150
PII26166
LINEAR
LWG 225
225
PII27166
LINEAR
LWG 500
500
PII28166
ROTATING
-
-
PII14166
-
MOUNTING KIT
-
PII16166
The mounting kit includes the following materials:
. N. 1 Magnetic support (1);
. N. 1 Adaptive arm (2);
. N. 1 Small mechanical clamp (3);
. N. 1 Big mechanical clamp (4);
. N. 1 Support for the rotating transducer (5).
. N. 1 Connection cable (6), 10 m long.
. N. 1 Rotary transducer (7) (or linear transducer, or both).
The kit is included into a plastic transport case. The following picture shows the open case.
