ISA CBA2000 - APPENDIX A: MENU SELECTIONS; 1 TRIGGER OPTIONS; 2 TEST OPTIONS; 3 RECORDING OPTIONS

Doc. SIE10169 Rev. 13 Page 29 of 32
APPENDIX A: MENU SELECTIONS
LEVEL 1
LEVEL 2
LEVEL 3
LEVEL 4
1 TRIGGER OPTIONS
1 Coil current
% of range (1 to 99)
2 Coil command
3 Coil command
reset
4 Analog input
1 Threshold, positive
or negative
2 input range
5 External trigger on
Slave input
6 Auxiliary input
1 Channel number
2 Logic level: NO,
NC, TRANSITION
3 Logic conditions:
AND, OR
2 TEST OPTIONS
1 Open
A, B, C, AB, BC, CA,
all; *
2 Close
3 Open – Close
4 Close – Open
5 Open – Close –
Open
6 Optional MTC
1 Battery voltage
2 V threshold, %
3 V threshold, V
7 Tolerances
Max trip time
Max close time
Pole discrepancy
open
Pole discrepancy
close
Contact discrepancy
open
Contact discrepancy
close
3 RECORDING
OPTIONS
1 Open coil duration
2 Close coil duration
3 Open to close delay
4 Close to open delay
5 Pretrigger duration
6 Sample frequency
7 Recording duration
8 Two recordings
1 First duration
2 Dead time
3 Second duration
9 Help diagram
Timing diagram
