2.4 INPUTS TIMING
. Sample rate: from 20 kHz maximum, for recording up to 1s to 20 Hz, for recording up to 1s 1000
s. See the table below for more details.
. Resolution: 0.1 ms to 100 ms.
. Inputs timing accuracy: see the following table.
RANGE
FREQUENCY
RESOLUTION
ACCURACY
1 s
20000 Hz
0.1 ms
0.1 ms ± 0.025% of the reading
2 s
10000 Hz
0.2 ms
0.2 ms ± 0.025% of the reading
4 s
5000 Hz
0.4 ms
0.4 ms ± 0.025% of the reading
10 s
2000 Hz
1 ms
1 ms ± 0.025% of the reading
20 s
1000 Hz
2 ms
2 ms ± 0.025% of the reading
40 s
500 Hz
4 ms
4 ms ± 0.025% of the reading
100 s
200 Hz
10 ms
10 ms ± 0.025% of the reading
200 s
100 Hz
20 ms
20 ms ± 0.025% of the reading
400 s
50 Hz
50 ms
50 ms ± 0.025% of the reading
1000 s
20 Hz
100 ms
100 ms ± 0.025% of the reading
2.5 ANALOG INPUT
Number of analog inputs: ten in all, programmable. Common characteristics of analog inputs:
. Measurement resolution: 16 bit.
. Measurement accuracy: 0.5% of the reading ± 0.1% of the selected range.
. Impedance: more than 200 kOhm.
. Measurement sampling rate: 20 kHz max.
2.5.1 Coil currents
The two coil current measurements; optionally four, above described are included in the total of ten
analog channels.
2.5.2 High voltage analog inputs
. Number: two, with no common point.
. Input voltage ranges: ± 5 V; ± 50 V; ± 500 V DC (3.5; 35; 350 V AC), user selected. These ranges
allow measuring all AC and DC voltages.
. Connection: via four safety sockets.
2.5.3 Low voltage analog inputs
. Number: three plus one.
. For all of them, the input voltage range is ± 10 V.
. Three of them are for transducers measurements or for analog input measurements, and have the
same reference point; the fourth one is dedicated to the micro-Ohmmeter.
. For the three inputs, they can be used for position or pressure transducers, or for analog signal
measurements.
