iScooter X02 - Ⅲ. Specefication

Scooter Unfolded Size* (L*W*H) 1100*500*950 mm
Scooter Weight* (N.W.) 42.75kg
Ground Clearance 85mm
Maximum Forward Speed 8km/h
Maximum Weight Capacity 120kg
Tyre Φ197*60 mm solid tyres
Brake Electromagnetic brake system
Range per Charge 20km
Battery 24V, 12Ah lead-acid battery
Charger Output DC 28.8V, 1.7A
Motor 24V, 250W
Controller 24V, 45A
Max Grade Ability 12°
07
*About the scooter size:
The length is the distance from the anti-collision bar to the anti-tip
wheels. The width is the distance from the rear left to the rear right
wheel.
The height is the distance from the ground to the top of the control
panel when the tiller is adjusted perpendicular to the ground.
*About the weight:
The weight is measured after the scooter is fully assembled
(including the basket).
III. SPECIFICATIONS
