iMC-B / iMC-V Operating Instruction
page - 15
Please note the default connection of the second input –port (E2.1
– E2.8) in the control software Remote / ProNC under the menu
entry „Signalization“.
These inputs are directly wired with the modules inside the
controller. You cannot longer use these inputs in the user
program!
➆ GND - 8-pin
➇ +24VDC- 8-pin
➈ AC-Input – net input module 115/230 VAC, 50 …60 Hz
The net input module consists of net input socket, net filter, fuse holder and net main
switch. Connect the controller via delivered net cable to a free receptacle. After that
you can switch on the controller with the net main switch.
➉ Spindle -115V/ 230V connector
Use this output connector to directly tap a working spindle without speed control.
Use the delivered mating connector. Maximum load of the relay output is 115/230 V
AC / 6A. The spindle start signal is switched by the integrated CAN-I/O-module and
will be analyzed by the security-circuit-module (iSM5). If all safety related conditions
are complied the 115/230 V AC voltage is switched on the connector.
Please note the pin assignment for the spindle start signal in
the table for the CAN-I/O-module in chapter 4.2.
The net input module consists of net input socket, net filter, fuse holder und net main
switch. Connect the controller via delivered net cable to a free receptacle. After that
you can switch on the controller with the net main switch.
⑪ Main spindle drive connector (optional)
Use this connector to tap speed controlled working spindle (asynchronous motor).
The (optional) frequency inverter is mounted inside the controller and will be
controlled over the security-circuit- and I/O-module.
