IWQ Series Service Manual
Items relating to buzzer
Set No. Setup title
Set value & functions
(Default underlined)
F15 Loud buzzer
• Buzzer may sound
immediately after the
power is turned ON
due to unstable
power characteristics
for an initial second.
0: Same time as internal buzzer;
1: When conditioned as “Over”;
2: When conditioned as “Accept”;
3: When conditioned as “Under”;
4: When scale stable;
5: On “Over” condition; when scale
stable;
6: On “Accept” condition; when
scale stable;
7: Outside range; when scale
stable;
8: Same time as internal buzzer;
9: When conditioned as “Over”;
10: When conditioned as “Accept”;
11: When conditioned as “Under”;
12: When scale stable;
13: Under “Over” condition; when
scale stable;
14: Under “Accept” condition; when
scale stable;
15: Outside range; when scale
stable;
Buzzer ON(normally OFF)
Buzzer ON(normally OFF)
Buzzer ON(normally OFF)
Buzzer ON(normally OFF)
Buzzer ON(normally OFF)
Buzzer ON(normally OFF)
Buzzer ON(normally OFF)
Buzzer ON(normally OFF)
Buzzer OFF(normally ON)
Buzzer OFF(normally ON)
Buzzer OFF(normally ON)
Buzzer OFF(normally ON)
Buzzer OFF(normally ON)
Buzzer OFF(normally ON)
Buzzer OFF(normally ON)
Buzzer OFF(normally ON)
F16 Internal buzzer 0: When stable outside range; <Successive “Blips”>
1: When stable under “Accept” condition; <Long continuous “Beeps”>
2: When stable under “Over” condition; <Successive “Blips”>
3: Buzzer OFF (neither key input sound)
4: Only during key input or when stable;
5: Only during key input
6: Upper/lower limits verification function;
(regardless of being stable/unstable)
UNDER: Successive “Blips” with an interval
ACCEPT : Long continuous “Beeps”
OVER : Successive “Blips”
