IWQ Series Service Manual
•Text layout 2 (for data output command)
♦Received text
Scale data demand 1
Command Terminator
Function: One time output upon receipt.
Character O 8 CR LF
Code (4FH) (38H) (0DH) (0AH)
Scale data demand 2
Command Terminator
Character O 9 CR LF
Function: One time output upon receipt
when transmission
conditions meet.
Code (4FH) (39H) (0DH) (0AH)
♦Response text
Affirmative response
(data output)
Condition: Normally executed in 1 second (O8 command).
Data output conditions meet (O9 command).
Preset output message
Timing: At completing command execution.
Negative response
Command
Character NAK
Code (15H)
Condition: Outside the range for scale operation.
No output within 1 second (for O8 command).
Having received an invalid text.
Having received an invalid command
Timing: Upon receiving an invalid text/command.
Upon verifying outside scale operation range.
1 second elapsed after receiving a command.
