ISHIDA NOVA-II - QB Series

16 Ishida Setup & Calibration Manual
3.1 QB Series
Follow the steps in the table below to set up and calibrate the QB Series scale.
NOTES:
• Press the P key to cancel calibration procedures and return to the weigh display.
• If
[o–Err] appears on the display, the weight exceeds the scale capacity.
• Standard calibration weight is
1/2 capacity. However, when possible, calibrate using a full capacity
weight. See the table below for the unit system capacities.
• If
[1–Err] appears on the display, the calibration weight is less than 50% of the standard.
• If
[2–Err] appears on the display, an object other than the calibration weight is on the pan, or the display
tolerance (1%) is exceeded.
Step Action
1Press and hold the F key until [Func] –> [CAL] appear in sequence, then release the key.
2Press and hold the T key, then press the F key, then release both keys.
3 [un it] appears. Press the T key to increase the value of the right digit in the following order:
[0] –> [1] –> [2] –> . . . .[9] –> [A] –> [6] –> [d] (repeat from 0).
Select the desired unit system number (see table below).
4Press the F key to call up [on 0]. The QB automatically performs a zero adjustment. (Do not leave any weight on
the pan).
5 After the QB performs zero adjustment, [on FS] automatically appears. Gently place the designated calibration
weight on the center weigh pan (see table below for designated calibration weights).
6 When calibration is complete, the scale automatically returns to the weighing mode.
Unit No. (mark) QB-150E QB-300E QB-600E QB-1500E QB-3000E QB-6000E QB-12KE QB-620E QB-6200E
1 (g) 150 300 600 1500 3000 6000 12000 620 6200
2 (kg) 0.15 0.3 0.6 1.5 3 6 12 0.62 6.2
3 (ct) 750 1500 3000 7500 15000 30000 60000 3100 31000
4 (oz) 5.2 10 21 52 100 210 420 21 210
5 (Lb) 0.33 0.66 1.3 3.3 6.6 13 26 1.3 13
6 (ozt) 4.8 9.6 19 48 96 190 380 19 190
7 (dwt) 96 190 380 960 1900 3800 7700 390 3900
8 (gr) 2300 4600 9200 23000 46000 92000 180000 9500 95000
9 (tl) 4 8 16 40 80 160 320 16 160
A (tl) 3.9 7.9 15 39 79 150 310 16 160
b (tl) 4 8 16 40 80 160 320 16 160
c (mom) 40 80 160 400 800 1600 3200 160 1600
