SETTINGS
18
User’s Manual WM3M4 &WM3M4C
Identification window:
Figure 16: WM3M4 Identification window
Figure 17: WM3M4C Identification window
 Type
 Serial number
 Software version
 Hardware version
 Accuracy class
 Calibration voltage
 Calibration current
 Communication
 Digital signature algorithm (supported only for WM3M4C)
 Public key: for further description see chapter 1.2.3.1. Generation of private/public key pair on
page 32 (valid only for WM3M4C).
 OCMF format version (valid only for WM3M4C)
Software references:
 Calibration date
 FW upgrade counter
 MID unlock counter
 MID lock status
 Software Checksum
 Calibration Data Checksum – CRC of calibration parameters.
 Phase module L1 – version of FW, CRC of FW and CRC of calibration parameters.
 Phase module L2 – version of FW, CRC of FW and CRC of calibration parameters.
 Phase module L3 – version of FW, CRC of FW and CRC of calibration parameters.
