Iso-Tech IDM 103N - Electrical Specifications - AC Current

32
(4) AC Current
Range
Accuracy
Voltage
Burden
103N 105N/106
40.00mA
±(1.5% + 5dgt)*
300mV max
400.0mA
3V max
10.00A
±(2.5% + 5dgt) ±(2.0% + 5dgt)
3V max
±(1.5% + 5dgt)*
Frequency Response : 40Hz ~ 1KHz.
AC Conversion Type :
103N / 105N : Average sensing rms indication.
106 : AC conversions are ac-coupled, true rms responding,
calibrated to the rms value sine wave input.
The specified accuracy is for since wave at full scale
and non-sine wave at half scale below 500Hz with crest
factor up to 2.
AC conversions are average sensing, calibrated to the
rms value sine wave input.
Overload Protection :
1A , 600V IR 10KA fuse (Bussmann BBS-1 or equivalent) for
mA input. (Size 10.3mm x 34.9mm)
15A , 600V IR 100KA fuse (Bussman KTK 15 or equivalent)
for A input. (Size 10.3mm x 38.1mm)
