Iso-Tech IDM 103N - Electrical Specifications - Resistance; Diode Check and Continuity Specifications

33
(5) Resistance
Open circuit Voltage : -1.3V approx.
Range
Accuracy
103N 105N/106
400.0Ω ±(0.7% + 3dgt) ±(0.7% + 3dgt)
4.000KΩ
±(0.6% + 3dgt)
40.00KΩ
400.0KΩ
4.000MΩ
±(0.7% + 3dgt) ±(0.6% + 3dgt)
40.00MΩ
±(1.5% + 5dgt) ±(1.5% + 5dgt)
±(0.4% + 2dgt)
(6) Diode Check and Continuity
Range Resolution Accuracy

1 mV
±(1.5% + 5 dgt)*
* For 0.4V ~ 0.8V
Max.Test Current : 1.5mA
Max. Open Circuit Voltage : 3V
Overload Protection : 600V rms.
Continuity : The internal sounder operates when resistance
is less than 30Ωapproximately.
