Iso-Tech IDM 103N - Electrical Specifications - Frequency;RPM; Electrical Specifications - Capacitance

34
Overload Protection : 600V rms.
* For 105N / 106 only.
** The spec is not guaranty.
Range Sensitivity Accuracy
4.000KHz / 40.00KRPM
150mV rms ≧ 20Hz
1.5V rms ≦ 20Hz
40.00KHz / 400.0KRPM
400.0KHz / 4.000KRPM
4.000MHz / 40.00MRPM 300mV rms
400.0MHz / 4.000MRPM **
Frequency :
±(0.01% + 1dgt)
RPM :
±(0.01% +
10dgt)
40.00MHz / 400.0MRPM 1V rms
(7) Frequency / RPM
(8) Capacitance
Range Accuracy Overload Protection
4.000nF
±(3.0% + 10 dgt)
600V rms
40.00nF
±(2.0% + 8 dgt)
400.0nF
4.000µF
40.00µF
400.0µF
4.000mF *
40.00mF *
±(5.0% + 20 dgt) **
