Isokern Standard 36 - Component List & Dimensions

DM Chimney Component List & Dimensions
30
12” HIGH
INNER LINER DM 54
12”
16 1/2”
12” or 14”
Note: DM 44 12” High Inner Liner will have a 6” or 8” Diameter Flue hole.
6” HIGH
INNER STARTER
LINER
16 1/2” 14”
6”
OUTER CASING
21 1/2” 21 1/2”
12”
6”
OFFSET BLOCK
21 1/2”
25”
3”
11”
OFFSET BLOCK
STACKED
3”
BRICK LEDGE
3”
31 1/2”
31 1/2”
LARGE
CROWN CAP
37 1/2”
37 1/2”
3”
13/16”
SMALL
CROWN CAP
26 1/4”
26 1/4”
13/16”
3”
