Removing the Old Room and Patio Stations
Because there are numerous old makes and models of existing intercoms, it is impossible
to describe in specific detail the process to remove the old room stations. The steps listed
below are general steps that may or may not apply to the specific make and model you are
replacing.
Remove the room station from the wall.
Disconnect the wires attached to the old room station and set it aside.
Leave any existing room station mounting rings installed. The Intrasonic Technology
Retrofit Room Stations come with an adapter plate that will mount to this existing ring.
Once the old room station has been removed and the wires disconnected, the existing station hole
with the existing mounting ring should look something like the above picture.
Intrasonic Technology, Inc. l 610 presidential Dr. Suite 104 l Richardson, Texas 75081 877-435-0670
Page 11 of 18
