Installing the new Room and Patio Stations
There are 2 adapter plates, one for vertical mounting and one for horizontal mounting with
each room station. Select the appropriate adapter plate and attach it to the existing
mounting ring with screws.
he view above shows the vertical adapter plate installed on the mounting ring.
Mount the plastic adapter frame to the metal adapter plate with the screws provided.
Intrasonic Technology, Inc. l 610 presidential Dr. Suite 104 l Richardson, Texas 75081 877-435-0670
Page 12 of 18
