Engine Control System (4HK1) 1A-103
DTC P0107 or P0108 (Flash Code 32)
Circuit Description
The boost pressure sensor is located in the air
induction tubing. The boost pressure sensor is a
transducer that varies voltage according to changes in
the air pressure inside the air tubing. The sensor has
the following circuits.
5 volts reference circuit
Low reference circuit
Boost pressure sensor signal circuit
The boost pressure sensor provides a signal to the
ECM on the signal circuit, which is relative to the
pressure changes in the air tubing. The ECM should
detect a low signal voltage at a low boost pressure,
such as low engine load. The ECM should detect high
signal voltage at a high boost pressure, such as high
engine load. If the ECM detects an excessively low or
high signal voltage, DTC P0107 or P0108 will set.
Condition for Running the DTC
DTCs P060B and P0697 are not set.
The battery voltage is between 18 to 32 volts.
The ignition switch is ON.
Condition for Setting the DTC
The ECM detects that the boost pressure sensor
signal voltage is less than 0.1 volts for 3 seconds.
(DTC P0107)
The ECM detects that the boost pressure sensor
signal voltage is more than 4.9 volts for 3 seconds.
(DTC P0108)
Action Taken When the DTC Sets
The ECM illuminates the MIL when the diagnostic
runs and fails. Refer to DTC Type Definitions for
Action Taken When the DTC Sets - Type A.
The ECM uses a boost pressure substitution of
default value.
The ECM inhibits EGR control.
Condition for Clearing the DTC
Refer to DTC Type Definitions for Condition for
Clearing the MIL/ DTC - Type A.
Diagnostic Aids
If an intermittent condition is suspected, refer to
Intermittent Conditions in this section.
Schematic Reference: Engine Controls Schematics
Connector End View Reference: Engine Controls
Connector End Views or ECM Connector End Views
Circuit/ System Testing DTC P0107
Step Action Value(s) Yes No
1
Did you perform the Diagnostic System Check
- Engine Controls?
Go to Step 2
Go to Diagnostic
System Check -
Engine Controls
2
1. Install a scan tool.
2. Turn OFF the ignition for 30 seconds.
3. Start the engine.
4. Monitor the DTC Information with a scan tool.
Is DTC P0697 also set?
Go to DTC P0697 Go to Step 3
3
Observe the Boost Pressure Sensor parameter
with a scan tool.
Is the Boost Pressure Sensor parameter less
than the specified value?
0.1 volts
Go to Step 4
Go to Diagnostic
Aids
4
1. Turn OFF the ignition.
2. Disconnect the boost pressure sensor
harness connector.
3. Connect a DMM between the 5 volts reference
circuit (pin 3 of E-24) and a known good
ground.
4. Turn ON the ignition, with the engine OFF.
Is the DMM voltage more than the specified
value?
4.5 volts
Go to Step 5 Go to Step 6
