Isuzu 2008MY N Series - Component Locator; Engine Controls Component Views

1A-12 Engine Control System (4HK1)
Component Locator
Engine Controls Component Views
Legend
1. Barometric pressure (BARO) sensor 2. Accelerator pedal position (APP) sensor
Legend
1. Boost pressure sensor
LNW81ASF000901
1
2
LNW76ESF001201
1
