Engine Control System (4HK1) 1A-293
Circuit/ System Testing DTC P2455
12
1. Reconnect all previously disconnected
harness connector(s).
2. Clear the DTCs with a scan tool.
3. Turn OFF the ignition for 30 seconds.
4. Start the engine.
5. Operate the vehicle within the Conditions for
Running the DTC. You may also operate the
vehicle within the conditions that you
observed from the Freeze Frame/ Failure
Records.
Did the DTC fail this ignition?
—
Go to Step 3 Go to Step 13
13
Observe the DTC Information with a scan tool.
Are there any DTCs that you have not
diagnosed?
—
Go to DTC List System OK
Step Action Value(s) Yes No
Step Action Value(s) Yes No
1
Did you perform the Diagnostic System Check
- Engine Controls?
—
Go to Step 2
Go to Diagnostic
System Check -
Engine Controls
2
1. Install a scan tool.
2. Turn OFF the ignition for 30 seconds.
3. Start the engine.
4. Observe the Exhaust Differential Pressure
Sensor parameter with a scan tool.
Is the Exhaust Differential Pressure Sensor
parameter more than the specified value?
4.9 volts
Go to Step 3
Go to Diagnostic
Aids
3
Monitor the DTC Information with a scan tool.
Is DTC P0697 also set?
—
Go to Step 4 Go to Step 5
4
1. Turn OFF the ignition.
2. Disconnect the exhaust differential pressure
sensor harness connector.
3. Turn ON the ignition, with the engine OFF.
Is the Exhaust Differential Pressure Sensor
parameter less than the specified value?
0.1 volts
Go to DTC P0697 Go to Step 7
5
1. Turn OFF the ignition.
2. Disconnect the exhaust differential pressure
sensor harness connector.
3. Turn ON the ignition, with the engine OFF.
Is the Exhaust Differential Pressure Sensor
parameter less than the specified value?
0.1 volts
Go to Step 6 Go to Step 7
6
Connect a test lamp between the low reference
circuit (pin 1 of J-33) and battery voltage.
Does the test lamp illuminate?
—
Go to Step 9 Go to Step 8
LG4HKED-WE-0871.book 293 ページ ２００７年１１月２９日 木曜日 午後６時２９分
To Next Page
