1A-118 Engine Control System (4HK1)
11
1. Inspect for an intermittent and for poor
connections at the harness connector of the
ECT sensor (pins 1 and 2 of E-25).
2. Repair the connection(s) as necessary.
Did you find and correct the condition?
—
Go to Step 15 Go to Step 13
12
1. Turn OFF the ignition.
2. Disconnect the ECM harness connector.
3. Inspect for an intermittent and for poor
connections at the harness connector of the
ECM (pins 84 and 109 of E-12).
4. Repair the connection(s) as necessary.
Did you find and correct the condition?
—
Go to Step 15 Go to Step 14
13
Replace the ECT sensor. Refer to ECT Sensor in
Section 1C Engine Cooling.
Did you complete the replacement?
—
Go to Step 15
—
14
Important: Replacement ECM must be
programmed and learned.
Replace the ECM. Refer to ECM Replacement.
Did you complete the replacement?
—
Go to Step 15
—
15
1. Reconnect all previously disconnected
harness connector(s).
2. Clear the DTCs with a scan tool.
3. Turn OFF the ignition for 30 seconds.
4. Start the engine.
5. Operate the vehicle within the Conditions for
Running the DTC. You may also operate the
vehicle within the conditions that you
observed from the Freeze Frame/ Failure
Records.
Did the DTC fail this ignition?
—
Go to Step 3 Go to Step 16
16
Observe the DTC Information with a scan tool.
Are there any DTCs that you have not
diagnosed?
—
Go to DTC List System OK
Step Action Value(s) Yes No
LG4HKED-WE-0871.book 118 ページ ２００７年１１月２９日 木曜日 午後６時２９分
