1A-210 Engine Control System (4HK1)
DTC P0563 (Flash Code 35)
Circuit Description
The ECM monitors the ignition voltage on the ignition
feed terminal to make sure that the voltage stays within
the proper range. If the ECM detects an excessively
high ignition voltage, this DTC will set.
Condition for Running the DTC
• DTC P060B is not set.
• The battery voltage is between 18 to 32 volts.
Condition for Setting the DTC
• The ECM detects that the ignition voltage feed
circuit is more than 32 volts for 30 minutes.
Action Taken When the DTC Sets
• The ECM illuminates the SVS lamp when the
diagnostic runs and fails. Refer to DTC Type
Definitions for Action Taken When the DTC Sets -
Type C. (Euro 4 specification)
• The ECM illuminates the MIL when the diagnostic
runs and fails. Refer to DTC Type Definitions for
Action Taken When the DTC Sets - Type A.
(Except Euro 4 specification)
Condition for Clearing the DTC
• Refer to DTC Type Definitions for Condition for
Clearing the SVS Lamp/ DTC - Type C. (Euro 4
specification)
• Refer to DTC Type Definitions for Condition for
Clearing the MIL/ DTC - Type A. (Except Euro 4
specification)
Diagnostic Aids
• A charging system problem may set this DTC.
Schematic Reference: Engine Controls Schematics
Connector End View Reference: Engine Controls
Connector End Views or ECM Connector End Views
Circuit/ System Testing DTC P0563
Step Action Value(s) Yes No
1
Did you perform the Diagnostic System Check
- Engine Controls?
—
Go to Step 2
Go to Diagnostic
System Check -
Engine Controls
2
Was the vehicle recently a battery charger
placed on the battery?
—
Go to Step 7 Go to Step 3
3
1. Install a scan tool.
2. Start the engine and let idle.
3. Observe the Ignition Voltage parameter with
the scan tool.
Does the scan tool indicate less than the
specified value?
32.0 volts
Go to Diagnostic
Aids Go to Step 4
4
Test the charging system. Refer to Charging
System in Section 1E Engine Electrical.
Did you find a charging system problem?
—
Go to Step 5
Go to Diagnostic
Aids
5
Repair the charging system. Refer to Charging
System in Section 1E Engine Electrical.
Did you complete the repair?
—
Go to Step 6
—
6
1. Reconnect all previously disconnected
harness connector(s).
2. Clear the DTCs with the scan tool.
3. Turn OFF the ignition for 30 seconds.
4. Start the engine and let idle.
5. Observe the ignition Voltage parameter with a
scan tool.
Does the scan tool parameter less than the
specified value?
32.0 volts
Go to Step 7 Go to Step 4
