1A-160 Engine Control System (4HK1)
12
Important: The CMP sensor may be damaged if
the sensor signal circuit is shorted to a voltage
source.
1. Test the signal circuit between the ECM (pin
98 of E-12) and the CMP sensor (pin 1 of E-
18) for a short to battery or ignition voltage.
2. Repair the circuit(s) as necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 18
13
1. Test the signal circuit between the ECM (pin
98 of E-12) and the CMP sensor (pin 1 of E-
18) for a short to any 5 volts reference.
2. Repair the circuit(s) as necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 18
14
1. Inspect for an intermittent and for poor
connections at the harness connector of the
CMP sensor (pins 1, 2 and 3 of E-18).
2. Repair the connection(s) as necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 16
15
1. Turn OFF the ignition.
2. Disconnect the ECM harness connector.
3. Inspect for an intermittent and for poor
connections at the harness connector of the
ECM (pins 87, 98, 100 and 101 of E-12).
4. Repair the connection(s) as necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 18
16
1. Inspect the CMP sensor and camshaft gear
for the following conditions:
• Physical damage of sensor
• Loose or improper installation of sensor
• Excessive air gap
• Foreign material passing between sensor
and camshaft gear
• Physical damage of camshaft gear
• Loose or improper installation of
camshaft gear
2. Repair or replace as necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 17
17
Replace the CMP sensor. Refer to CMP Sensor in
Section 1B Engine Mechanical.
Did you complete the replacement?
—
Go to Step 19
—
18
Important: Replacement ECM must be
programmed and learned.
Replace the ECM. Refer to ECM Replacement.
Did you complete the replacement?
—
Go to Step 19
—
Step Action Value(s) Yes No
