1A-252 Engine Control System (4HK1)
6
1. Remove the Meter (10A) fuse that supplies
voltage to the SVS lamp.
2. Turn ON the ignition, with the engine OFF.
3. Measure the voltage from the SVS lamp
control circuit in the ECM harness connector
(pin 17 of J-14) to a known good ground.
Is the voltage less than the specified value?
1 volt
Go to Step 7 Go to Step 13
7
1. Turn OFF the ignition.
2. Reinstall the Meter (10A) fuse.
3. Turn ON the ignition, with the engine OFF.
4. Connect a 3-amp fused jumper wire between
the ECM harness connector (pin 17 of J-14)
and a known good ground.
Is the SVS lamp illuminated?
—
Go to Step 11 Go to Step 8
8
1. Connect a test lamp between the ignition
voltage feed circuit of the IP cluster harness
connector (pin 2 of B-105) and a known good
ground.
2. Turn ON the ignition, with the engine OFF.
Does the test lamp illuminate?
—
Go to Step 9 Go to Step 14
9
1. Test the control circuit between the ECM (pin
17 of J-14) and the IP cluster (pin 4 of B-106)
for an open circuit or high resistance.
2. Repair the circuit(s) as necessary.
Did you find and correct the condition?
—
Go to Step 17 Go to Step 10
10
1. Inspect for an intermittent and for poor
connections at the harness connector of the
IP cluster (pins 2 of B-105 and pin 4 of B-106).
2. Repair the connection(s) as necessary.
Did you find and correct the condition?
—
Go to Step 17 Go to Step 15
11
1. Inspect for an intermittent and for a poor
connection at the harness connector of the
ECM (pin 17 of J-14).
2. Repair the connection(s) as necessary.
Did you find and correct the condition?
—
Go to Step 17 Go to Step 16
12
Repair the short to ground between the ECM (pin
17 of J-14) and the IP cluster (pin 4 of B-106).
Did you complete the repair?
—
Go to Step 17
—
13
Repair the short to battery or ignition voltage
between the ECM (pin 17 of J-14) and the IP
cluster (pin 4 of B-106).
Did you complete the repair?
—
Go to Step 17
—
14
Repair the open circuit or high resistance on the
ignition voltage feed circuit between the Meter
(10A) fuse and the IP cluster (pin 2 of B-105).
Did you complete the repair?
—
Go to Step 17
—
15
Repair or replace the IP cluster. Refer to Instrument
Panel (IP) Cluster in Section 9E Instrumentation /
Driver Info.
Did you complete the repair or replacement?
—
Go to Step 17
—
Step Action Value(s) Yes No
