Engine Control System (4HK1) 1A-37

Diagnostic System Check - Engine Controls (Except Euro 4 Specification)

Step Action Value(s) Yes No

Install a scan tool.

Does the scan tool turn ON?

—

Go to Step 2

Go to Scan Tool

Does Not Power Up

1. Turn ON the ignition, with the engine OFF.

2. Attempt to establish communication with the

listed control modules.

•ECM

• Transmission control module (TCM)

(Smoother only)

• Hill start aid (HSA) control unit (If so

equipped)

• Supplemental restraint system (SRS)

control unit (If so equipped)

Does the scan tool communicate with all the

listed control modules?

—

Go to Step 3

Go to Scan Tool

Does Not

Communicate with

Keyword Device

Notice: If an immobilizer system is active the ECM

will disable the fuel injection causing the engine to

stall immediately after starting and energize the

starter cut relay to disable cranking. Attempt to

crank the engine.

Does the engine crank?

—

Go to Step 4 Go to Step 5

Attempt to start the engine.

Does the engine start and idle?

—

Go to Step 6

Go to Engine

Cranks but Does

Not Run

Does the scan tool display ECM DTCs P0633,

P161B or U0167?

—

Go to Applicable

DTC

Problem is relating

to starting system.

Refer to Starting

System in Section

1E Engine Electrical

Select the DTC display function for the following

control modules:

• ECM

• TCM (Smoother only)

• EHCU (If so equipped)

• HSA control unit (If so equipped)

• SRS control unit (If so equipped)

Does the scan tool display any DTCs?

—

Go to Step 7 Go to Step 11

Does the scan tool display DTCs which begin

with U or other control module communication

fault DTCs?

—

Go to Applicable

DTC Go to Step 8

Does the scan tool display ECM DTCs P0601,

P0602, P0604, P0606, P060B or P1621?

—

Go to Applicable

DTC Go to Step 9

Does the scan tool display ECM DTC P0563?

—

Go to Applicable

DTC Go to Step 10

Is there any other code in any controller that

has not been diagnosed?

—

Go to Applicable

DTC Go to Step 11

Is the customer's concern with the

transmission?

—

Go to Diagnostic

System Check -

Transmission

Controls in Setion

5A Transmission

Control System Go to Step 12
