1A-88 Engine Control System (4HK1)
5
1. Turn OFF the ignition.
2. Disconnect the FRP regulator harness
connector.
3. Connect a test lamp between the high side
circuit (pin 1 of E-17) and a known good
ground.
4. Turn ON the ignition, with the engine OFF.
Does the test lamp illuminate?
Go to Step 6 Go to Step 9
6
1. Turn OFF the ignition.
2. Connect a test lamp between the low side
circuit (pin 2 of E-17) and battery voltage.
3. Turn ON the ignition, with the engine OFF.
Does the test lamp illuminate?
Go to Step 11 Go to Step 10
7
1. Test the high side circuits between the ECM
(pins 105 and 113 of E-12) and the FRP
regulator (pin 1 of E-17) for a short to battery
or ignition voltage.
2. Repair the circuit(s) as necessary.
Did you find and correct the condition?
Go to Step 15 Go to Step 14
8
1. Test the low side circuits between the ECM
(pins 89 and 97 of E-12) and the FRP
regulator (pin 2 of E-17) for a short to ground.
2. Repair the circuit(s) as necessary.
Did you find and correct the condition?
Go to Step 15 Go to Step 14
9
1. Test the high side circuits between the ECM
(pins 105 and 113 of E-12) and the FRP
regulator (pin 1 of E-17) for the following
conditions:
An open circuit
A short to ground
A short to the low side circuit
High resistance
2. Repair the circuit(s) as necessary.
Did you find and correct the condition?
Go to Step 15 Go to Step 12
10
Important: The ECM may be damaged if the FRP
regulator low side circuit is shorted to a voltage
source.
1. Test the low side circuits between the ECM
(pins 89 and 97 of E-12) and the FRP
regulator (pin 2 of E-17) for the following
conditions:
An open circuit
A short to battery or ignition voltage
High resistance
2. Repair the circuit(s) as necessary.
Did you find and correct the condition?
Go to Step 15 Go to Step 12
11
1. Inspect for an intermittent and for poor
connections at the harness connector of the
FRP regulator (pins 1 and 2 of E-17).
2. Repair the connection(s) as necessary.
Did you find and correct the condition?
Go to Step 15 Go to Step 13
Step Action Value(s) Yes No
