1A-94 Engine Control System (4HK1)
11
1. Inspect the fuel system line connections
between the fuel tank and the fuel supply
pump for tightness and all fuel hoses for cuts,
cracks and for the use of proper clamps.
2. Repair or replace as necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 12
12
1. Turn OFF the ignition.
2. Disconnect the FRP regulator harness
connector.
3. Inspect for an intermittent, for poor
connections and corrosion at the harness
connector of the FRP regulator (pins 1 and 2
of E-17).
4. Disconnect the ECM harness connector.
5. Inspect for an intermittent, for poor
connections and corrosion at the harness
connector of the ECM (pins 89, 97, 105 and
113 of E-12).
6. Test for high resistance on each circuit.
7. Repair the connection(s) or circuit(s) as
necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 18
13
1. Turn OFF the ignition.
2. Disconnect the FRP sensor harness
connector.
3. Inspect for an intermittent, for poor
connections and corrosion at the harness
connector of the FRP sensor (pins 1, 2 and 3
of E-19).
4. Disconnect the ECM harness connector.
5. Inspect for an intermittent, for poor
connections and corrosion at the harness
connector of the ECM (pins 82, 87, 90 and
101 of E-12).
6. Test for high resistance on each circuit.
7. Repair the connection(s) or circuit(s) as
necessary.
Did you find and correct the condition?
—
Go to Step 19 Go to Step 15
14
Replace the fuel filter element. Refer to Fuel Filter
Element in Section 1D Engine Fuel .
Did you complete the replacement?
—
Go to Step 19
—
15
Replace the FRP sensor. Refer to Fuel Pressure
Sensor in Section 1D Engine Fuel.
Did you complete the replacement?
—
Go to Step 19
—
16
Important: Replacement fuel injector must be
programmed.
Replace the appropriate fuel injector that was
leaking fuel found at Step 3 and inspect the engine
mechanical for any damage or poor engine
compression. Refer to Injector in Section 1D
Engine Fuel.
Did you complete the replacement?
—
Go to Step 19
—
Step Action Value(s) Yes No
LG4HKED-WE-0871.book 94 ページ ２００７年１１月２９日 木曜日 午後６時２９分
