ENGINE ASSEMBLY ( 3 )
19. Oil Filter
Tighten the oil filter bolts to the specified torque.
Oil Filter Bolt Torque kgf·m(lb.ft/N·m)
1.4 – 2.4 (10.1 – 17.3/13.7 – 23.5)
107
15. Alternator and Adjusting Plate
Tighten the alternator bolts and the adjusting plate
bolts to the specified torque.
Alternator Bolt Torque kgf·m(lb.ft/N·m)
3.6 – 4.6 (26.0 – 33.3/35.3 – 45.1)
Tighten the adjusting plate bolts to the specified
torque after cooling drive belt installation.
Adjusting Plate Bolt Torque kgf·m(lb.ft/N·m)
1.4 – 2.4 (10.1 – 17.3/13.7 – 23.5)
To Next Page
