LEO Instructions
Edition: 01/2016 - Revision: 01/16
Uponmachinearrival,
ensure it has not been
damaged.
Ifallisinorder,remove
thecardboardorplastic
protectingthemachine.
Whenyoumovethepallet
wheretherobotislocated
DONOTcutthestrapthat
blockit.
Pay particular attention
when unpacking as the
machine is also made of
plastic parts that are not
resistant to violent impacts.
ThepalletwrapperrobotLEOisshippedfullyassembledandsecuredtothepalletwithappro-
priate strapping.
Cut the strap to free it from the pallet.
Ground movement and positioning
Toliftandmovethemachinestillpositionedon
thepallet,insertaØ20mmbarintheholeindi-
catedbythearrowinFigure12andliftitusinga
forkliftasindicatedinFigure12.
INSTALLATION
Machine unpacking
a
CAUTION
The machine must be lifted and handled by qualied technicians and
authorized to perform these operations.
Move body and hands away when the machine is lowered.
Failure to observe these instructions may cause serious injury.
WARNING
Always perform unloading and handling operations using lifting means with
adequate capacity to the weight of the machine.
4 - 01
12
11
10
