Inspection and Installation
3. Press the Left/Right key to select LAN and press [Enter].
4. Press the Left/Right key to select Serv-Conf and press [Enter].
5. Rotate the knob to select the service you want to enable and press
[Enter].
6. Rotate the knob to select whether to enable the service and press
[Enter].
– On: Indicates that the service is enabled.
– Off: Indicates that the service is disabled.
2.6.2.1 Using Web Server
The instrument has a built-in Web server for monitoring and controlling the in-
strument via a Web browser in PC. To use the Web server, connect the instru-
ment and PC over LAN interface and enter the instrument's IP address into the
address bar at the top of your PC's Web browser, you can access the front pan-
el control functions including the LAN configuration parameters.
• If you want to remotely control the instrument using the built-in web server, you
must enable the web service. See 2.6.2 LAN Interface for details.
• The format of the address entered in the address bar of the browser is http://
192.168.0.100. The specific IP address is subject to the actual instrument
settings.
The opened page is displayed as follows:
Copyright © Itech Electronic Co., Ltd.
40
