Power Supply Function
Initial Value
Set the initial state of
charge (SOC) of the bat-
tery. 0~100% corre-
sponds to the voltage
range from no-load volt-
age to full-load voltage.
Open
Open or select a user-defined battery
emulation file.
Recall File
Set the file save
address.
Edit
Edit a user-defined battery simulation
file.
Full Voltage
Simulates the voltage
value when the cell bat-
tery is fully charged.
Empty
Voltage
Simulates the voltage
value when the cell bat-
tery is in the empty
state.
Inner
Resistance
Simulates the internal
resistance of a cell
battery.
Capacity
Simulates the capacity
of a cell battery.
Parallel
Set the number of paral-
lel connected batteries.
Serial
Set the number of bat-
teries in series.
I+
Positive current limit val-
ue, which simulates the
maximum discharge cur-
rent of the battery pack.
I-
Negative current limit
value, which simulates
the maximum charge
current of the battery
pack.
Copyright © Itech Electronic Co., Ltd.
108
