Technical Specification
Parameter IT6015C-80-450
Command Response Time
2mS
Power Factor 0.99
Storage Temperature
-10℃～70℃
Protective Function
OVP, OCP, OPP, OTP and Vsense reversed protection
Standard Interface
Standard: USB, CAN, LAN, VCP; optional: GPIB, analog card
(includes RS232), fiber optic socket
Isolation ( output to ground)
500V
Working Temperature
0～50℃
Dimension ( mm) 483mm(W)*801.61mm(D)*151.3mm(H)
Weight( net)
40KG
6.1.2 300V
6.1.2.1 IT6006C-300-75
Parameter IT6006C-300-75
Rated value
Output Voltage
0～300V
( 0 ℃-50 ℃) Output Current
-75～75A
Output Power
-6000～6000W
Output Resistance
0～1Ω
Line Regulation
Voltage
≤0.01%FS
Current ≤0.05%FS
Load Regulation
Voltage
≤0.02%FS
Current ≤0.05%FS
Setup Resolution
Voltage
0.01V
Current 0.001A
Power 0.001kW
Resistance 0.01Ω
Read Back Resolution
Voltage
0.01V
Current 0.001A
Power 0.001kW
Resistance 0.01Ω
